Hand hold type

Y24 hand-held rock drill

Model Number: Y24
Weight: 24 KG
Drilling diameter :34-42 mm
Piston stroke: 70 mm
Product description: Y24 hand-held rock drill is a trans-formative product of our air leg rock drill YT24 . With advanced technology level, it is very suitable for the second blasting and downward drilling in quarries.
INQUIRY Email Whatsapp

Y24 hand-held rock drill

Y24 hand-held rock drill is a trans-formative product of our air leg rock drill YT24 . With advanced technology level, it is very suitable for the second blasting and downward drilling in quarries.

In addition to maintaining the excellent performance of YT24, Y24 is also enhanced with the ability of purging blast hole. Therefore, it is more suitable for drilling downward blast hole.

Air consumption	≤55L/S
Percussive Frequency	≥27 HZ
Air Pressure	0.63Mpa
Drill Depth	5M
N.W/ Length	24KG / 604MM
Drilling diameter	34-42 mm
Piston diameter	70mm
Piston stroke	70 mm
