DTH hammer

8 inch Halco DTH hammers

Hammer Size: 1” to12”
Product description: 8 inch Halco DTH hammers |Dominator 750|Dominator 800|Dominator 850 are user friendly and reliable. They are built using the highest quality heat treated nickel chrome alloy steels thereby delivering
INQUIRY Email Whatsapp

Halco 8" DTH Hammer Range

Hammer	Dominator 750	Dominator 800	Dominator 800	Dominator 800
Part Number	600243	600310	600308	600309
Shank	Sandvik Mission A63-15/SD8	Halco Mach 80	Sandvik Mission A63-15/SD8	IR DHD 380
Top Thread	4 1/2” Api Reg Pin	4 1/2” Api Reg Pin	4 1/2” Api Reg Pin	4 1/2” Api Reg Pin
Hammer Flat Size	115mm (4.528”)	156mm (6.142”)	156mm (6.142”)	156mm (6.142”)
Weight	165 kg	175 kg	180 kg	181 kg
Outside Diameter	172mm (6.772”)	182mm (7.165”)	182mm (7.165”)	182mm (7.165”)
Make Up Length	1232mm (48.504”)	1180mm (46.456”)	1180mm (46.456”)	1180mm (46.456”)
Rec. Min. Thrust	800kg (1760 Lbs)	800kg (1760 Lbs)	800kg (1760 Lbs)	800kg (1760 Lbs)
Rec. Max. Thrust	2000kg (4400 Lbs)	2000kg (4400 Lbs)	2000kg (4400 Lbs)	2000kg (4400 Lbs)

Hammer	Dominator 800 LE	Dominator 850	Dominator 850 DW
Part Number	600396	600245	600314
Shank	IR QL 80	IR QL 80	IR QL 80
Top Thread	4 1/2” Api Reg Pin	4 1/2” Api Reg Pin	4 1/2” Api Reg Pin
Hammer Flat Size	127mm (5")	125mm (4.921”)	125mm (4.921”)
Weight	178 Kg	210 kg	210 kg
Outside Diameter	182mm (7.165")	192mm (7.559”)	192mm (7.559”)
Make Up Length	1244mm (48.976")	1281mm (50.433”)	1281mm (50.433”)
Rec. Min. Thrust	800 Kg (1760 Lbs)	800 Kg (1760 Lbs)	800 Kg (1760 Lbs)
Rec. Max. Thrust	2000 Kg (4400 Lbs)	2000 Kg (4400 Lbs)	2000 Kg (4400 Lbs)

Hammer	Dominator 880	Dominator 880	Dominator 880DW
Part Number	600311	600312	600261
Shank	Sandvik Mission A63-15/SD8	IR DHD 380	IR DHD 380
Top Thread	4 1/2” Api Reg Pin	4 1/2” Api Reg Pin	4 1/2” Api Reg Pin
Hammer Flat Size	156mm (6.142”)	156mm (6.142”)	156mm (6.142”)
Weight	177 kg	177 kg	177 kg
Outside Diameter	182mm (7.165”)	182mm (7.165”)	182mm (7.165”)
Make Up Length	1263mm (49.724”)	1263mm (49.724”)	1263mm (49.724”)
Rec. Min. Thrust	800kg (1760 Lbs)	800kg (1760 Lbs)	800kg (1760 Lbs)
Rec. Max. Thrust	2000kg (4400 Lbs)	2000kg (4400 Lbs)	2000kg (4400 Lbs)

Halco hammers are user friendly and reliable. They are built using the highest quality heat treated nickel chrome alloy steels thereby delivering exceptional productivity and durability. Halco strives for continual improvement and utilizes a specially designed comprehensive and coordinated quality system to ensure customer satisfaction through top quality products.
