5 inch Halco DTH hammers

Hammer Size: 3” to12”
Product description: 5 inch Halco DTH hammers are user friendly and reliable. They are built using the highest quality heat treated nickel chrome alloy steels thereby delivering exceptional productivity and durability. H
INQUIRY Email Whatsapp

Halco 5" DTH Hammer Range

Hammer	Mach 50	Dominator 500	Dominator 500	Super Dominator 500
Part Number	600046	600120	600135	600267
Shank	Halco Mach 50	Halco Mach 50	Sandvik Mission A43-15	IR DHD 350R
Top Thread	3 1/2” Api Reg Pin	3 1/2” Api Reg Pin	3 1/2” Api Reg Pin	3 1/2” Api Reg Pin
Hammer Flat Size	90mm (3.544”)	90mm (3.544”)	90mm (3.544”)	90mm (3.544”)
Weight	54 Kg	58 Kg	58 Kg	58 Kg
Outside Diameter	114mm (4.5”)	118mm (4.65”)	118mm (4.65”)	118mm (4.65”)
Make Up Length	1012mm (40”)	980mm (38.60”)	980mm (38.60”)	975mm (38.40”)
Rec. Min. Thrust	400 Kg (900 Lbs)	400 Kg (900 Lbs)	400 Kg (900 Lbs)	400 Kg (900 Lbs)
Rec. Max. Thrust	900 Kg (1980 Lbs)	900 Kg (1980 Lbs)	900 Kg (1980 Lbs)	900 Kg (1980 Lbs)

Hammer	Super Dominator 550 HD	Super Dominator 550 HD QL 50	GW500 HD	GW500 HD
Part Number	600293	600294	600390	600401
Shank	IR DHD 350R	IR QL50	IR DHD 350	IR DHD 350
Top Thread	3 1/2” Api Reg Pin	3 1/2” Api Reg Pin	2 3/8” Api Reg Pin	3 1/2” Api Reg Pin
Hammer Flat Size	90mm (3.544”)	90mm (3.544”)
Weight	67 kg	67 kg	60 kg	60 kg
Outside Diameter	124.5mm (4.85”)	124.5mm (4.85”)	126mm (4.961”)	126mm (4.961”)
Make Up Length	975mm (38.40”)	955mm (37.60”)	1074mm (42.283”)	1074mm (42.283”)
Rec. Min. Thrust	400 kg (900 Lbs)	400 kg (900 Lbs)	400 kg (900 Lbs)	400 kg (900 Lbs)
Rec. Max. Thrust	900 kg (1980 Lbs)	900 kg (1980 Lbs)	900 kg (1980 Lbs)	900 kg (1980 Lbs)

Halco hammers are user friendly and reliable. They are built using the highest quality heat treated nickel chrome alloy steels thereby delivering exceptional productivity and durability. Halco strives for continual improvement and utilizes a specially designed comprehensive and coordinated quality system to ensure customer satisfaction through top quality products.
