1.Description of the 150mm Continuous Diamond Blade with Turbo Type For Cutting Stone
Sintered turbo continuous saw blades are designed for cutting Ceramic Tiles, Floor Tiles, Quarry Tiles, Marble, Terrazzo, Slate, Terrazzo, Nature Stone, Fiber Glass Products, Plastic, General building materials, etc.
Outer diameter of Sintered turbo continuous saw also can be done from 4 inch to 14 inch. Segment height and center hole can be done upon client's request. Bond and diamond can be adjustable upon customer's request by our engineers to cut specific materials.
2. Features of the 150mm Continuous Diamond Blade with Turbo Type For Cutting Stone
a) Smooth and fast cutting without chipping
b) Long lifespan and stable performance
c) Competitive price and superior quality
d) Fast delivery
e) Different grade to choose
3. Specification Information of the 150mm Continuous Diamond Blade with Turbo Type
1) Diameter: 150mm
2) Hole size: 20/22.23 or do as your request
3) Matched machines: Angle grinder, Table saw, Hand held saw.
4) Cutting Materials: Various kinds of marble. Granite sandstone, limestone, concrete, etc.
5) Delivery time: Around 20days
|
Item No. |
Diameter |
Segment dimension |
Inner hole |
||
|
Inch |
mm |
Thickness |
Height |
||
|
STGR-T01-150 |
6 |
150 |
2.4 |
7/10 |
20/22.23 |
Other size of Diamond Sintered Blade with turbo type
|
Item No. |
Diameter |
Segment dimension |
Inner hole |
||
|
Inch |
mm |
Thickness |
Height |
||
|
STGR-T01-105 |
4 |
105 |
2.2 |
7/10 |
16/20 |
|
STGR-T01-110 |
4.3 |
110 |
2.2 |
7/10 |
16/20 |
|
STGR-T01-115 |
4.5 |
115 |
2.2 |
7/10 |
20/22.23 |
|
STGR-T01-125 |
5 |
125 |
2.2 |
7/10 |
20/22.23 |
|
STGR-T01-180 |
7 |
180 |
2.4 |
7/10 |
20/22.23 |
|
STGR-T01-200 |
8 |
200 |
2.6 |
7/10 |
20/22.23 |
|
STGR-T01-230 |
9 |
230 |
2.6 |
7/10 |
20/22.23 |
|
STGR-T01-250 |
10 |
250 |
2.8 |
10 |
20/25.4 |
|
STGR-T01-300 |
12 |
300 |
3 |
10 |
20/25.4 |
|
STGR-T01-350 |
14 |
350 |
3.2 |
10 |
25.4 |
