Single Roller Cone Bit

  • 9 1/2 inch IADC537 Replaceable Single Roller Cone
  • 9 1/2 inch IADC537 Replaceable Single Roller Cone
9 1/2 inch IADC537 Replaceable Single Roller Cone9 1/2 inch IADC537 Replaceable Single Roller Cone

9 1/2 inch IADC537 Replaceable Single Roller Cone

  • Size:9 1/2 inch
  • Weight: 17 Kgs
  • Use: Well Drilling
  • Single package size: 18X18X35 cm
  • Product description: 9 1/2 inch IADC537 Replaceable Single Roller Cone
  • INQUIRY Email Whatsapp

9 1/2 inch IADC537 Replaceable Single Roller Cone

Samples: IADC537

$300.00/Piece|1 Piece (Min. Order)

Product Name
9 1/2" IADC537 Single Roller Cone Single Roller Cutter for Rotary Drilling
Diameter
9 1/2"
Model
537G
Pin Thread
API Reg. 6 5/8"
Sealed Bearing
O-Ring Sealed Journal Bearing
Normal WOB
0.5~1.05 KN/MM (Bit Diameter)
Gross / Net Weight
17 Kgs
Rotary Speed
100~50 RPM
Cutting Structure
Offset crested scoop compacts in inner row,wedge compacts in outer row,imequable spaced compacts arrangement,and a row of trimmers is added between gage row and heel row
Drilling Formation
Medium soft with low compressive strength and harder abrasive stringers,such as hard shale,hard gypsolyte,soft limestone,sandstone and dolomite with stringers,etc.
