DTH hammer

12 inch Halco DTH hammers

Hammer Size: 3” to12”
Product description: 12 inch Halco DTH hammers are user friendly and reliable. They are built using the highest quality heat treated nickel chrome alloy steels thereby delivering exceptional productivity and durability.
INQUIRY Email Whatsapp

Halco 12" DTH Hammer Range

Hammer	Mach 120	Mach 122	Mach 132	Mach 142
Part Number	600108	600110	600142	600143
Shank	Sandvik Mission A100-15/SD12	Sandvik Mission A100-15/SD12	IR DHD 112	IR DHD 112S
Top Thread	6 5/8” Api Reg Pin	6 5/8” Api Reg Pin	6 5/8” Api Reg Pin	6 5/8” Api Reg Pin
Hammer Flat Size
Weight	614 kg	614 kg	614 kg	688 kg
Outside Diameter	273mm (10.748”)	273mm (10.748”)	273mm (10.748”)	273mm (10.748”)
Make Up Length	1667mm (65.629”)	1667mm (65.629”)	1684mm (66.299”)	1819mm (71.614”)
Rec. Min. Thrust	1600 kg (3520 Lbs)	1600 kg (3520 Lbs)	1600 kg (3520 Lbs)	1600 kg (3520 Lbs)
Rec. Max. Thrust	3500 kg (7700 Lbs)	3500 kg (7700 Lbs)	3500 kg (7700 Lbs)	3500 kg (7700 Lbs)

Hammer	Super Dominator 1200
Part Number	600373
Shank	IR QL 120
Top Thread	6 5/8” Api Reg Box
Hammer Flat Size	260mm (10.236”)
Weight	807 kg
Outside Diameter	284mm (11.181”)
Make Up Length	1978mm (77.874”)
Rec. Min. Thrust	1600 Kg (3520 Lbs)
Rec. Max. Thrust	3500 Kg (7700 Lbs)

Halco hammers are user friendly and reliable. They are built using the highest quality heat treated nickel chrome alloy steels thereby delivering exceptional productivity and durability. Halco strives for continual improvement and utilizes a specially designed comprehensive and coordinated quality system to ensure customer satisfaction through top quality products.
