1. Soft to medium-hard formation application
Medium Parabolic crown profile and heavy cutter density provide high ROP in medium to hard formations with medium compressive strength and small abrasive layers.
2. Multi-function hydraulics
The deep blade design can get high ROP in medium to hard formations and can effectively cool the bit in hard and abrasive formations
3. Longer Bit Life
High intensified gage design provides for long runs on steerable system through hard and abrasiive formations as steering application.
Technical Data
| Regular Models of PDC Bits | |||
| Regular Sizes | Regular IADC | API Reg Pin | Make-up Torque(N.m) |
| 3 7/8"(98.4mm) | 126/216/637 | 2 3/8 | 4100~4700 |
| 4 5/8"(117.4mm) | 126/216/517/537/637 | 2 7/8 | 6100~7500 |
| 5 1/4"(133.3mm) | 3 1/2 | 9500~12200 | |
| 5 5/8"(142.8mm) | |||
| 5 7/8"(149.2mm) | |||
| 6"(152.4mm) | 126/127/216/517/537/617/637 | ||
| 6 1/4"(158.7mm) | |||
| 6 1/2"(165mm) | |||
| 7 1/2"(190mm) | 126/216/517/537 | 4 1/2 | 16300~21700 |
| 7 5/8"(193mm) | |||
| 7 7/8"(200mm) | |||
| 8 1/2"(215.9mm) | 117/127/217/437/517/537/617/637 | ||
| 9 1/2"(241.3mm) | 6 5/8 | 38000~43400 | |
| 9 7/8"(250.8mm) | |||
| 10 5/8(269.8mm) | |||
| 11 5/8(295.3mm) | |||
| 12 1/4"(311.1mm) | |||
| 13 5/8"(346.0mm) | 127/217/517/537/617/637 | ||
| 14 3/4"(374.6mm) | 7 5/8 | 46100~54200 | |
| 17 1/2"(444.5mm) | 114/115/125/215/515/535/615/635 | ||
| 26"(660.4mm) | 114/115/125/215/515/535/615 | ||
