PDC Bit

API 6 1/2 inch 5 Blades Steel Body PDC Bit Oil well drilling PDC rock bit

diameter: 61/2inch(165mm)
primary cutter size: 1616
usage: water well drilling, hole drilling
weight: 35kg
Product description: API 6 1/2 inch 5 Blades Steel Body PDC Bit Oil well drilling PDC rock bit
INQUIRY Email Whatsapp

API 6 1/2 inch 5 Blades Steel Body PDC Bit Oil well drilling PDC rock bit

$950.00/Piece|1 Piece (Min. Order)

Basical Specification
product name	API 6 1/2" 5 Blades Steel Body PDC Bit Oil well drilling PDC rock bit
diameter	6 1/2
blade number	5 blades
Type	steel body
primary cutter size	1616
connection thread	41/2" API Reg pin
usage	water well drilling, hole drilling
application formation	soft to medium hard rock formation

Please select the applicable formation and parameters according to the instructions.

Carefully check the bits appearance and to check the bits threaded end face,whether the serial number on the box and certificate.

Selection of WOB and RPM should be within the limits of the recommended parameters, higher WOB and RPM cannot be used simultaneously.

Bottom hole must be clean and bit must not be used for long section reaming.

Drilling process must operate smoothly, find that there is Bie jump on abnormal phenomenon, should be timely analysis and take effective measures

The bit should be kept indoor with dry and well ventilated conditions at 10-33℃ and kept from sunshine and rain. Stored under such conditions, quality of bit is guaranteed for 4 years.
